Photograph taken by myself of an SD2IEC connected to a C64. The SD2IEC is connected to the serial port but a separate connector takes power from the datasette port. Therefore the datesette cannot be connected at the same time. Note that the KCS Power Cartridge on the right is disconnected. This cartridge uses so much power that the SD2IEC does not function when the cartridge is also connected.
